Silicone rubber extruded seals
Silicone rubber, a kind of polymer material, is featured with nontoxicity, environment-friendliness, high-and low-temperature resistance, ageing resistance, weather resistance. Our company is engaged in customized production of all kinds of silicone rubber sealing strips in U-type, P-type, E-type, D-type, L-type and other irregular type, with the sealing performance meeting the sealing requirements of all kinds of electronic appliances and lighting equipment.
| Raw material | Silicone rubber | |||||
| Manufacturing process | Certification | Hardness (Shore A) | Tensile strength (Mpa) | Elongation at break (%) | Tearing strength (kN/mm) | Operating temperature range (℃) |
| Extrusion solid | ROHS FDA REACH, etc. | 30-85 | 6-10 | 250-700 | 16-50 | -100-315 |
| Extrusion foaming | ROHS FDA REACH, etc. | 20-45 | 1.5-4.5 | 200-400 | 10-20 | -55-315 |
■The above data are data of general products under lab conditions, with test conditions beingDCBP, 1.2%, 110℃X10min
■In addition to data in the above chart, our company can also provide products with better performance according to customer’s requirements. Please contact our marketing personnel for further information.
Silicone rubber molded structural parts
Silicone rubber has been widely applied to the electronic appliances field due to its excellent performance. Our company is engaged in customized production of all kinds of silicone rubber molded structural parts in square, round and other irregular shapes. In addition to achieving the general properties, our company can also produce other silicone rubber products with electrical conductivity, thermal conductivity, fire resistance and other special properties.
| Raw material | Silicone rubber | |||||
| Manufacturing process | Certification | Hardness(Shore A) | Tensile strength (Mpa) | Elongation at break (%) | Tearing strength (kN/mm) | 使用温度范围(℃) |
| Molding solid | ROHS FDA REACH, etc. | 15-90 | 6-10 | 150-800 | 18-50 | -100-315 |
| Molding foaming | ROHS FDA REACH, etc. | 10-45 | 1.5-4.5 | 250-500 | 10-20 | -55-315 |
■The above data are data of general products under lab conditions, with test conditions beingDBPH with the concentration of 50%, 1.2%,170℃X10min,
■In addition to data in the above chart, our company can also provide products with better performance according to customer’s requirements. Please contact our marketing personnel for further information.
Key Attributes:
✔️ Heat/Cold Resistant** (-60°C to +230°C)
✔️ Medical & Food Safe** (FDA compliant)
✔️ Cut-to-Length
Ideal For:
– Waterproofing LED light housings
– Chemical lab equipment sealing
– Industrial oven gaskets
**Customization: Click “Contact Supplier” for drawings or samples!
